WT30x Smart Fan Coil Thermostat

Description

Milesight WT301&WT302 is an advanced touch screen roomthermostatspecifically developed to oversee fan and valve operations in air conditionerapplications where fan coil unit (FCU) is adopted. It achieves thisbycontinuously comparing the environmental temperature with thepre-setdesiredtemperature, enabling both proactive management and automaticcontrol basedon predefined logic. This ensures optimal comfort and energy efficiencyinthecontrolled environment. With wireless detection and easy configuration, the WT301&WT302offersreliable and convenient room temperature arrangement optimization. Itiscompatible with standard LoRaWAN® gateway, enabling real-timemonitoringofenvironmental status for effective remote management.

Main Features

 Adjust the room temperature automatically and manually with a time-controlled regulation

 Applicable for two pipes and 3-Speed fan coil system, compatible with On/Off relay (WT301) or 0-10V(WT302) valve control

 5+1+1 six periods programmable maximize comfort and economy

 High accuracy of 0.5°C for temperature regulation, enabling precise control of indoor temperaturelevels

 Adopts an LCD screen with Four-color LED and capacitive touch buttons, providing a better interactiveexperience

 With clock display function

 With a 12cm ultra-thin embedded panel and a sleek, frameless design, it effortlessly blends intodifferent interior styles, offering a minimalist and elegant appearance  Equips with external NTC sensor signal input and keycard switch input

 Function well with standard LoRaWAN® gateways and network servers

 Easy to install with the compact size  Highly adapt to different scenarios with 86mm hidden box and European 60mmround box
